ltems | Standard | |
Operating temperature range | -20℃ to +70℃ | |
Electrical performance |
Rating | 50mA..12V DC |
Insulation resistance | 100MΩ min.100V DC | |
Dielectric strength | 250V AC for 1 min. | |
Contact resistance | 100mΩ max. | |
Durability | Lifetime | N:300,000 Cycles C100,000 Cycles |
Mechanical performance |
Operating force | J:160gf C:250gf |
Travel | 0.27 ± 0.05mm |
Proudcts | Dimensions | Circuit Diagram |
Pad Layout | ||
|
